SE501 Connected Riding Display
SE501 6.1-Inch Motorcycle CarPlay Display with Dual 1080P Dash Cam
The Arvov SE501 motorcycle car play display combines wireless Apple CarPlay, Android Auto, dual 1080P recording, GPS support, optional Bluetooth TPMS and supported 4G remote monitoring in one motorcycle-ready platform.
Navigation, Recording and Remote Visibility
A Motorcycle Apple CarPlay Display Built for Connected Riding
SE501 brings phone projection, ride recording and vehicle-status functions to a dedicated 6.1-inch screen. It supports Apple CarPlay, Android Auto, HiCar and CarLife projection, helping riders use compatible navigation, calls and media without relying on the phone as the primary handlebar display.
Wireless Phone Projection
Apple CarPlay for Motorcycle Navigation, Calls and Media
Connect a compatible iPhone or Android phone to use supported navigation, communication and media functions on the motorcycle display. SE501 supports wireless projection through Apple CarPlay, Android Auto, HiCar and CarLife.
- Wireless phone screen projection
- 2.4 GHz Wi-Fi and Bluetooth 5.0 connectivity
- Wireless Bluetooth remote control
- Multi-language interface support
Dual-Camera Recording
Front and Rear 1080P Motorcycle Dash Camera
Dual front and rear cameras record at 1920 × 1080P and 30 FPS with a specified 150-degree field angle. Loop recording, automatic recording, WDR and a supercapacitor-based design support everyday riding and evidence capture.
Dual 1080P Video
Front and rear recording provides coverage in both riding directions.
Loop Recording
Continuous recording support helps manage storage during longer rides.
G-Sensor and WDR
Specified G-sensor and WDR functions support recording in changing riding conditions.
Optional TPMS and GPS
Tire Pressure Monitoring, Positioning and Route Review
Optional Bluetooth TPMS sensors can monitor tire pressure and temperature in 2-, 3- or 4-wheel configurations. GPS support enables position information and route-tracking review through the supported application workflow.
- Optional Bluetooth tire-pressure sensors
- 2-, 3- and 4-wheel TPMS configurations
- GPS positioning and route review support
- Multi-user App sharing and real-time monitoring support
Supported 4G Configuration
Remote 4G Live View and Motorcycle Fleet Visibility
A supported 4G configuration enables remote vehicle-status viewing, live video, photo or video capture and positioning functions through the compatible App and platform. OTA online upgrade and motorcycle fleet-platform support can be discussed for project configurations.
- Remote live video and vehicle-status viewing
- Remote positioning and route visibility
- OTA online upgrade support
- Motorcycle fleet-management project support
Technical Data
SE501 Motorcycle CarPlay Specifications
Specifications are based on the supplied SE501 product document. Confirm the final configuration, package contents, optional TPMS and regional 4G requirements before ordering.
| Model | SE501 |
|---|---|
| Product size / display weight | 160 × 82 × 22 mm / 210 g |
| Display | 6.1-inch, 1440 × 720 |
| Phone projection | Apple CarPlay, Android Auto, HiCar and CarLife |
| Cameras | Front and rear 1920 × 1080P at 30 FPS; 150° field angle |
| Water resistance | Camera lens: IP68; main unit: IP67; remote control: IP67 |
| Recording | TS video format; loop recording and automatic recording supported |
| Processor | QZV533 |
| GPS / G-sensor / WDR | Supported |
| Power system | Supercapacitor; 10–30 V vehicle input with 5 V power conversion |
| Operating temperature | −20°C to 70°C |
| Storage support | 32–128 GB |
| Connectivity | 2.4 GHz Wi-Fi and Bluetooth 5.0 |
| TPMS | Optional Bluetooth sensors for 2-, 3- or 4-wheel monitoring |
| 4G / OTA / platform | Supported according to ordered configuration and regional service requirements |
Frequently Asked Questions
Motorcycle CarPlay Display FAQ
Does the SE501 support Apple CarPlay for motorcycle navigation?
Yes. SE501 supports wireless Apple CarPlay for compatible iPhones, allowing supported navigation, calls and media functions to appear on the motorcycle display.
Does this Apple Car Play motorcycle display support Android phones?
Yes. The supplied specification lists Android Auto, HiCar and CarLife in addition to Apple CarPlay. Compatibility depends on the phone and supported projection platform.
Are Bluetooth TPMS sensors included as standard?
TPMS is an optional configuration. Bluetooth sensors can be specified for 2-, 3- or 4-wheel pressure and temperature monitoring.
Is the complete SE501 display IP68 waterproof?
No. The supplied specification lists IP68 for the camera lens and IP67 for the main unit and wireless remote control. Installation should follow the supplied product guidance.
What resolution do the front and rear cameras record?
Both cameras are specified at 1920 × 1080P and 30 FPS with a 150-degree field angle.
Does 4G remote monitoring require a SIM card?
Yes. Remote 4G functions require a compatible SIM card, mobile data service and the supported App or platform configuration. Regional compatibility should be confirmed before ordering.
How much storage does the motorcycle dash camera support?
The supplied specification lists support for 32 GB to 128 GB storage. Confirm card type, included capacity and compatibility for the ordered package.
Can Arvov supply SE501 samples and OEM/ODM customization?
Yes. Contact Arvov with the target market, required configuration, quantity, branding and platform requirements to discuss samples and qualified OEM/ODM projects.
Need a Motorcycle CarPlay Display for Your Project?
Send Arvov your target market, camera, TPMS, 4G, branding and quantity requirements. We will help confirm the appropriate SE501 configuration for sample evaluation or volume supply.
