MXC-852 Car Dash Cam
MXC-852 4K+2K+2K Triple Channel Car Dash Cam
The Arvov MXC-852 is a triple channel car dash cam that records the road ahead in 4K, the cabin in 2K and rear traffic in 2K. It combines a 3.39-inch IPS display, built-in 2.4GHz Wi-Fi, mobile app support, G-sensor collision locking and optional GPS.
Triple Channel Coverage
4K dashboard camera for front, cabin and rear recording
MXC-852 provides three simultaneous camera views for passenger vehicles, rideshare fleets, distributors and OEM/ODM projects. Front 4K, cabin 2K and rear 2K recording help document road conditions, in-vehicle activity and traffic behind the car.
4K+2K+2K Recording
Three-camera coverage with wide viewing angles
The three-camera system records the road ahead, vehicle cabin and rear traffic at the same time. The front, cabin and rear cameras provide respective viewing angles of 170°, 130° and 140°. An F1.8 aperture, WDR and automatic recording support clear everyday driving documentation.
- Front 4K, cabin 2K and rear 2K recording
- 170° front, 130° cabin and 140° rear viewing angles
- 25 fps recording specification
- G-sensor collision footage locking
Wi-Fi & App Control
Built-in 2.4GHz Wi-Fi for convenient file access
Connect a compatible smartphone to preview supported camera views, manage recorded files and adjust available settings. Important footage can be reviewed, downloaded or shared through the supported mobile app workflow without removing the TF card.
- Built-in 2.4GHz Wi-Fi module
- Compatible mobile app support
- Recorded-file viewing and management
- Convenient clip download and sharing
Loop Recording
Continuous recording with up to 512GB TF card support
Loop recording automatically overwrites the oldest unlocked files when the selected TF card becomes full, helping the camera continue recording. MXC-852 supports 32GB to 512GB TF cards; the card is not included unless specified for the order.
- 32GB–512GB TF card support
- Automatic overwrite of older unlocked files
- Collision-locked files remain protected
- Actual recording time varies by settings and use
Vehicle Protection
Parking monitoring, time-lapse recording and optional GPS
Parking monitoring and time-lapse recording require a compatible hardwiring kit and correct vehicle installation. GPS is an optional configuration that should be confirmed before ordering.
Hardwiring required
A compatible hardwiring kit is required for parking monitoring and time-lapse recording.
Optional GPS
Choose the optional GPS configuration when supported route and location information is required.
Automotive power design
A super capacitor and 10–30V vehicle input specification suit automotive power environments.
Specifications
MXC-852 technical specifications
| Model | MXC-852 |
|---|---|
| Channel configuration | Triple channel: front + cabin + rear |
| Screen | 3.39-inch IPS LCD display |
| Product weight | 210 g |
| Recording resolution | Front 4K + cabin 2K + rear 2K at 25 fps |
| Viewing angles | Front 170° / cabin 130° / rear 140° |
| Lens / aperture | 2G4P / F1.8 |
| Video format | TS |
| Recording functions | Loop recording and automatic recording supported |
| CPU | iCatch V36 |
| Image sensors | GC4653 + SC2336 + 5080 CMOS |
| GPS | Optional |
| G-sensor / WDR | Supported |
| Power storage | Super capacitor |
| Input voltage | 10–30V vehicle input, regulated to 5V |
| Operating temperature | −20°C to 70°C |
| TF card storage | 32GB–512GB |
| Wi-Fi / app | Built-in 2.4GHz Wi-Fi; compatible app supported |
| Languages | Multilingual interface |
Project Configuration
Package contents and OEM/ODM support
Confirm camera positions, cable routing, storage, optional GPS and hardwiring requirements before ordering.
Package contents
Main unit, interior camera, rear camera, rear-camera extension cable, car charger, installation pry tool, printed manual and neutral packaging.
Optional equipment
GPS and a compatible hardwiring kit should be specified according to the required functions.
OEM/ODM projects
Discuss logo branding, packaging, interface languages, accessories and documentation requirements before production.
FAQ
MXC-852 car dash cam questions
What does the MXC-852 triple channel dash cam record?
It records front 4K, cabin 2K and rear 2K video simultaneously at the stated 25 fps specification.
What are the viewing angles of the three cameras?
The front camera covers 170°, the cabin camera covers 130° and the rear camera covers 140°.
Does the MXC-852 support Wi-Fi and app control?
Yes. It includes built-in 2.4GHz Wi-Fi and supports a compatible mobile app.
Is GPS included as standard?
No. GPS is an optional configuration that should be confirmed before ordering.
What TF card capacity does the MXC-852 support?
It supports TF card storage from 32GB to 512GB.
Does parking monitoring require a hardwiring kit?
Yes. Parking monitoring and time-lapse recording require a compatible hardwiring kit.
Project Inquiry
Discuss your MXC-852 car dash cam project
Tell us your required configuration, accessories, target market, branding and expected quantity.
